Hobart PROFI AMXXL Pass Through Dishwasher
Hobart PROFI AMXXL Pass Through Dishwasher
Couldn't load pickup availability
Features
Features
Four wash cycles: 60, 90, 180 seconds and Special Programmes
Up to 60 racks (1080 plates) per hour (500 x 500mm basket - 18 plates)
1 x Plate rack, 1 x Tray Rack, 1 x Cutlery basket
VISIOTRONIC control interface on the hood with colour-coded display allows for easily checking the machine's status at a glance
Improved counterbalanced Hood and Handle design makes operation as smooth as possible
Improved Wash and Rinse arms are self-flushing for easier cleaning and better hygiene
Self-cleaning machine chamber reduces manual cleaning
Improved wash chamber reduces the need for dirt traps and makes cleaning easier
For corner or straight through operation
Integrated WiFi module, designed to work with the Hobart WASHSMART app
A unique "turbo" wash power option, selectable on any cycle
Deep Drawn wash tracks
Automatic self flushing drain cycle on machine shut down
INTENSIV wash system delivers outstanding results and significantly reduces running costs
Supplied with integral fitted drain pump - allows quick and easy emptying and refilling
Class A Airgap – allows direct connection to mains and complies with all water authority bye-laws
Interlocked strainer
Accurate integral detergent and rinsing dosing equipment
Genius X² removes 20-40% more debris from the wash water
Unique 4-sided, fully insulated hood with ‘wrap around’ handle
440mm hood opening. Extra large opening heights which allow double racking of cups and saucers/side plates
Made in Germany
Specifications
Specifications
Basket Size - 500 x 500 (mm)
Loading Height - 540 (mm)
Wash Temperature - 60 Degrees
Rinse Temperature - 82 Degrees
Wash tank Capacity - 40 litres
Water Consumption/cycle - 2 litres
Water Pressure Req. - Cold or hot feed, 0.5 - 10.0 BAR 300 centilitre
Electrical Loading - 3 Phase 15.9kW 400/50/3 (fuse at 3 x 32A) Switchable to 12.4kW 400/50/3 (fuse at 3 x 20A) or 9.7kW 400/50/3 (fuse at 3 x 16A)
Model Code - AMXXL-10C
Dimensions (mm):
Height - 2195 with hood open
Width - 803 with handle (735 between tables)
Depth - 742
Shipping Options
Shipping Options
Free 2 - 4 Working Day Standard Delivery to UK mainland
Warranty
Warranty
Warranty - 1 Year Parts and Labour
Share
Description
12 & 24 month interest free credit is available on this unit, find out more
The AMXXL-10C is an excellent pass through dishwasher with a large chamber and increased flexibility. Designed to handle high volumes of washware, it’s also ideal for oversized items like pans and utensils, all within a compact footprint that means even more commercial kitchens can take advantage of the benefits of a pass through type dishwasher.
Options:
- Water softener - optional. If required please see our full range of external water softeners or see the Hobart PROFI AMXXLS
- Optimised Vapostop ER recycles steam for greater energy efficiency and improved kitchen environment
- Improved Drain Heat Recovery reduces your energy use by heat transfer from outgoing hot water to incoming cold water
Complete Your Setup
Hobart offers a range of standard inlet and outlet tabling in set sizes to create a complete, efficient washing station. If the standard sizes aren’t suitable, we can also supply bespoke tabling made to your exact requirements — explore Hobart tabling options.
For all AMX units we offer a FREE site survey
For sites in hard water areas we strongly recommend a water softener is fitted to eliminate limescale damage.
This unit is book and build, therefore delivery time may vary
*Tabling not included
This unit replaced the AMXXL-10B
High-Capacity Cleaning Power
This model features four wash cycles, 60, 90, 180 seconds, plus Special Programmes, giving you the flexibility to handle different loads with ease. With the ability to process up to 60 racks (or 1,080 plates) per hour, and an extended 440mm hood opening, it supports double racking for cups, saucers, and side plates.
Efficient by Design
The Genius X² filtration system boosts efficiency by removing 20–40% more food debris from the wash water, which can reduce detergent usage by up to 40%. The fully insulated, four-sided hood, complete with a wrap-around handle helps retain heat and steam, lowering your energy consumption during operation.
Simple, Smart Operation
Everyday use is made simple with clearly positioned hood-mounted controls. For added convenience, the built-in WiFi module links with the Hobart WASHSMART app, giving you access to live updates and diagnostics, wherever you may be.
